SS88C9N3F8

Low-Power Microcontroller with Integrated Power Management and On/Off Charging

SS88C9N3F8SS88C9N3F8

SS88C9N3F8

SS88CX is an 8-bit low-power microcontroller developed by Sinhmicro that integrates power management and on/off charging functions. It has a clear MCU memory architecture, complete system-level control, and built-in rich interface functions, flexible configuration modes and different low-power options. The product is mainly applied to portable smart electronic devices that require charging and intelligent control, with streamlined peripheral costs, superior overall performance, and flexible and convenient development
SS88C9N3F8
SS88CX is an 8-bit low-power microcontroller developed by Sinhmicro that integrates power management and on/off charging functions. It has a clear MCU memory architecture, complete system-level control, and built-in rich interface functions, flexible configuration modes and different low-power options. The product is mainly applied to portable smart electronic devices that require charging and intelligent control, with streamlined peripheral costs, superior overall performance, and flexible and convenient development
Product Details
Design / Development
Technical Documentation
Applications

Product Details

Technical Documentation

Parameter NameParameter Value
PackageQFN24L 3x3x0.85
BAT Power Supply Range2.7-4.8V
VIN Power Supply Range3.2 ~ 5.5V
Abs. VIN(Max)7.5V
LDOs & RegulatorVINLDO,BATLDO
Charge TopologyBuck
Boost current(Max)-
Charge Voltage Range4.1 ~ 4.5V
Charge Current(Max)2000mA
Code Flash Size (kB)8
Code Flash TypeMTP
Data Flash or EEPROM Size(B)128
RAM Size (B)192
Parameter NameParameter Value
Operating Frequency (MHz)12
Timers3
Other timer functionsWDG,SysTick,Always Timer
Number of PWMs7
Number of A/D Converters1
Number of ADC channels10
I/Os17
I2C-
UART1
SPI-
Other PeripheralsACMP,NTC
Boost Voltage Range-
Parameter NameParameter Value
PackageQFN24L 3x3x0.85
BAT Power Supply Range2.7-4.8V
VIN Power Supply Range3.2 ~ 5.5V
Abs. VIN(Max)7.5V
LDOs & RegulatorVINLDO,BATLDO
Charge TopologyBuck
Boost current(Max)-
Charge Voltage Range4.1 ~ 4.5V
Charge Current(Max)2000mA
Code Flash Size (kB)8
Code Flash TypeMTP
Data Flash or EEPROM Size(B)128
RAM Size (B)192
Operating Frequency (MHz)12
Timers3
Other timer functionsWDG,SysTick,Always Timer
Number of PWMs7
Number of A/D Converters1
Number of ADC channels10
I/Os17
I2C-
UART1
SPI-
Other PeripheralsACMP,NTC
Boost Voltage Range-
