SC8726A

High Efficiency, Synchronous, Buck-Boost Converter with Four Integrated MOSFET

SC8726ASC8726A

SC8726A

SC8726A is a synchronous 4-switch buck-boost converter with four integrated switches. It is able to effectively output voltage no matter it is higher, lower or equal to the input voltage. SC8726A supports very wide input and output voltage range. It can support applications from 2.7V to 22V input range and 2.4V to 22V output range. Through its I2C interface, user can program the output voltage and output current limit and switching frequency. VINREG voltage can be adjusted by external resistor. SC8721 employs current-mode control and supports output current limit, dynamic output voltage adjustment, internal current limit, output short protection and over temperature protections to ensure safety under different abnormal conditions. The IC is in a 21 pin 4x4 QFN package.
SC8726A
SC8726A is a synchronous 4-switch buck-boost converter with four integrated switches. It is able to effectively output voltage no matter it is higher, lower or equal to the input voltage. SC8726A supports very wide input and output voltage range. It can support applications from 2.7V to 22V input range and 2.4V to 22V output range. Through its I2C interface, user can program the output voltage and output current limit and switching frequency. VINREG voltage can be adjusted by external resistor. SC8721 employs current-mode control and supports output current limit, dynamic output voltage adjustment, internal current limit, output short protection and over temperature protections to ensure safety under different abnormal conditions. The IC is in a 21 pin 4x4 QFN package.
Product Details
Design / Development
Technical Documentation
Applications

Product Details

Design / Development

Parameters
Value
EVM Model
SC8726A EVM
Key Part Number
SC8726A
Input Voltage
Supports 2.7V to 22V input
functionality
Supports I2C voltage and current regulation

Technical Documentation

Parameter NameParameter Value
VIN range2.7-22V
Abs. VIN (max)25V
VOUT range2.4-22V
Iout(Max)5A
MOSint.
fsw260kHz ~ 920kHz
Parameter NameParameter Value
I2C Ctrl√
Prog. VoutI2C
Constant Current Mode√
IOUT monitorCSO pin
PFM√
PackageQFN 4x4
Parameter NameParameter Value
VIN range2.7-22V
Abs. VIN (max)25V
VOUT range2.4-22V
Iout(Max)5A
MOSint.
fsw260kHz ~ 920kHz
I2C Ctrl√
Prog. VoutI2C
Constant Current Mode√
IOUT monitorCSO pin
PFM√
PackageQFN 4x4
