SC8562

High Voltage 4:1 Switched-Capacitor Charger

SC8562SC8562

SC8562

SC8562 is a high efficiency, 5V/12A slave charger using a switched cap architecture. With its internal 17 low Rdson MOSFET and external flying caps, it can be configured into six different operation modes: forward 4:1/2:1/1:1 charger mode and reverse 1:4/1:2/1:1 converter mode. The switched cap architecture and the integrated FETs are optimized to enable a 50% cycle, decreasing the cable current to be quarter of the current delivered to the battery, reducing the losses over the charging cable as well as limiting the temperature rise in the application. SC8562 adopts 132pin CSP 4.885mm X 4.485mm package.
SC8562
SC8562 is a high efficiency, 5V/12A slave charger using a switched cap architecture. With its internal 17 low Rdson MOSFET and external flying caps, it can be configured into six different operation modes: forward 4:1/2:1/1:1 charger mode and reverse 1:4/1:2/1:1 converter mode. The switched cap architecture and the integrated FETs are optimized to enable a 50% cycle, decreasing the cable current to be quarter of the current delivered to the battery, reducing the losses over the charging cable as well as limiting the temperature rise in the application. SC8562 adopts 132pin CSP 4.885mm X 4.485mm package.
Product Details
Design / Development
Technical Documentation
Applications

Product Details

Technical Documentation

Parameter NameParameter Value
Pout_Typ.60W
VBUS range3.3~21V
Abs. Vbus (max)28V
Vout range2.7~5V
Abs. Vout (max)6V
Parameter NameParameter Value
Max Charge Current12A
Typ. Quiescent Current20uA
ADC resolution12 bit
IBUS accuracy±5%
PackageWLCSP132-4.855mm x 4.455mm
Parameter NameParameter Value
Pout_Typ.60W
VBUS range3.3~21V
Abs. Vbus (max)28V
Vout range2.7~5V
Abs. Vout (max)6V
Max Charge Current12A
Typ. Quiescent Current20uA
ADC resolution12 bit
IBUS accuracy±5%
PackageWLCSP132-4.855mm x 4.455mm
