Quad Channel 50-mΩ Smart High Side Driver with Advanced Protections and Diagnostics
SC77450CQ
The SC77450CQ is a fully-protected Quad channel smart
high side driver qualified in automotive grade. Full
diagnostics and high accuracy current sense of each
channel enable intelligent control of the load even in harsh
conditions. It integrates four-channel 50mΩ MOSFETs in a
compact package size with advanced protections of
overload current shutdown, dynamic thermal swing
shutdown, absolute thermal shutdown, fault latch-off in over
temperature events and over load events Besides, A
multiplexed pin delivers these analog signals of fault
indication for over load and over temperature in on-state
and open load in off-state.
