SC70563

1000mA Fully Integrated Linear Charger for 1Cell Li-ion Battery with VINDPM

SC70563SC70563

SC70563

1000mA Fully Integrated Linear Charger for 1Cell Li-ion Battery with VINDPM

The SC70563x is a highly integrated linear charger for 1 cell Li-ion battery applications. It supports up to 1000mA charging current and provides battery charge management functions including trickle charge, constant current charge, constant voltage charge, charge termination and charging status indication.
SC70563
The SC70563x is a highly integrated linear charger for 1 cell Li-ion battery applications. It supports up to 1000mA charging current and provides battery charge management functions including trickle charge, constant current charge, constant voltage charge, charge termination and charging status indication.
Product Details
Design / Development
Technical Documentation
Applications

Product Details

Technical Documentation

Parameter NameParameter Value
VIN range4.5-6V
Abs. VIN (max)26.5V
Abs. VBAT (max)±8V
IQ_BAT250nA
Battery Cell #1s
MOSint.
Parameter NameParameter Value
Charge Current (max)1000mA
Charge Voltage4.2V/4.35V/4.4V
Constant Charge Threshold2.9V
NTC√
VIN DPM√
PackageESOP-8
Parameter NameParameter Value
VIN range4.5-6V
Abs. VIN (max)26.5V
Abs. VBAT (max)±8V
IQ_BAT250nA
Battery Cell #1s
MOSint.
Charge Current (max)1000mA
Charge Voltage4.2V/4.35V/4.4V
Constant Charge Threshold2.9V
NTC√
VIN DPM√
PackageESOP-8
