SC5008

15W Full-Bridge Power Stage with Voltage/Current Demodulation for Highly-Integrated Wireless Power Transmitter

SC5008SC5008

SC5008

15W Full-Bridge Power Stage with Voltage/Current Demodulation for Highly-Integrated Wireless Power Transmitter

The SC5008 is a highly integrated analog-front-end that contains all of the analog components required to implement a wireless power transmitter compliant with WPC specifications. The device integrates a full-bridge power stage with low-RDS(on) MOSFETs, gate drivers, 5V & 3.3V LDOs, communication demodulators and input current sensing circuit. It can work with a transmitter controller to create a high-performance and cost-effective wireless power transmitter system that complies with WPC QI 1.3 & 2.0.
SC5008
The SC5008 is a highly integrated analog-front-end that contains all of the analog components required to implement a wireless power transmitter compliant with WPC specifications. The device integrates a full-bridge power stage with low-RDS(on) MOSFETs, gate drivers, 5V & 3.3V LDOs, communication demodulators and input current sensing circuit. It can work with a transmitter controller to create a high-performance and cost-effective wireless power transmitter system that complies with WPC QI 1.3 & 2.0.
Product Details
Design / Development
Technical Documentation
Applications

Product Details

Design / Development

Parameters
Value

Technical Documentation

Parameter NameParameter Value
Pout_max15W
ProtocolQI1.3/2.0
Pvin range3.2~18V
Avin rangeNA
Abs. SW (max)20V
Rdson4* 12mΩ
Parameter NameParameter Value
MCUNA
MTPNA
ADC resolutionNA
IQ1mA
PackageQFN-19 3mm * 4mm
Parameter NameParameter Value
Pout_max15W
ProtocolQI1.3/2.0
Pvin range3.2~18V
Avin rangeNA
Abs. SW (max)20V
Rdson4* 12mΩ
MCUNA
MTPNA
ADC resolutionNA
IQ1mA
PackageQFN-19 3mm * 4mm
